Technical Data Unistack 3000
| Format length min./max. | 6"-28⅓" |
| Stack production min./max. | 6"-12½" |
| Deep pile production min./max. | 11"-28⅓" |
| Stacking height (stack production) | 2,000 sheets (240 mm) |
| Stacking height (deep pile production) | 600 mm |
| Web width min./max. | 100 mm / 520 mm |
| Speed (DIN A4) | up to 350 m/min |
| Outfeed height of cross pushing unit | 650 mm / 860 mm reception height |
| Number of streams | 1/2 |
| Paper weights | 60-400 gsm |
| Operating side (eligible) | right/left according to customer information |
| Infeed height shingle stream | 950-1,050 mm |
| Electrical data | 3 LNPE 400/230 V 16A |
| Options: Version for 4-up production Static blocking unit Strip inserter Banding, wrapping and shrinking units | |
