Technical Data S-74-3
| Format length | 6"-13" |
| Stacking height min. | 5 mm |
| Stacking height max. | 250 mm |
| Web width min./max. | 210 mm / 740 mm |
| Speed (DIN A4) | up to 350 m/min |
| Speed (DIN A4) with CI version | up to 200 m/min |
| Sheet/Cardboard weights with CI version | 80-1,000 gsm |
| Outfeed height of reception belt | 650 mm / 860 mm reception height |
| Number of streams | 1/2/3 |
| Paper weights | 60-400 gsm |
| Options: Version 5-up production Integrated sheet/cardboard cutter Additional inserter for feeding of top/bottom sheet/cardboard Static blocking unit Strip inserter Banding, wrapping and shrinking units | |
